Handheld Homogenizer

YBOTECH Mini Overhead Stirrer is used for standard mixing of the higher viscosity substances. They essentially are mixers, used for suspending, gas intrusion and recirculation.

Overhead Stirrers are competent for most demanding tasks with guaranteed safety and performance. They are widely used in chemical synthesis, pharmaceutical synthesis, physical and chemical analysis, petrochemical industries, etc.

Inquire
Brochure Download
Feature
  • Portable, lightweight with ergonomic design ideal for manual operations
  • Processing volumes from 0.1-50mL or 1-250mL
  • Variable speed from 8,000 to 32,000 rpm
  • 316L stainless steel shafts are fully autoclavable
  • Handheld Homogenizer
  • Interchangeable shafts for easy dismantling and cleaning depending on shaft chosen.
Application

Designed for rapidly homogenize, emulsify, suspend and disrupt biological samples like tissue of animal, bacteria, yeast, plant samples, etc. in liquids. Ideal for samples from 0.1mL to 250mL depending on shaft chosen.

Handheld Homogenizer

Specifications D-160
Speed range 8000-32000rpm
Max linear velocity 6.3m/sec or 14m/sec
Speed leve 10 stage
Working volume (H2O) 0.1-50mL (Dispersing shaft DS-160/5)
Max. viscosity 5,000mPas
Material of Dispersing Shaft SS 316L stainless steel, PTFE
Noise 72 dB(A)
Protection class IP20
Voltage, Frequency 110-120V/60Hz
220-240V/50-60Hz
Power 160W
Motor Type AC carbon brush motor
Dimension (WxDxH) 45mm x 55mm x 190mm
Weight 0.54 kg
Permissible ambient temperature and humidity 0-40℃, 85%RH
