Ybotech vacuum drying oven is an earlier drying device, and the inside of the oven is divided into several layers by heating plates. Hot water or low-pressure steam is passed into the heating plate as the heating medium, the material pan with the medicine to be dried is placed on the heating plate, the door of the box is closed, and the inside of the box is vacuumed with a vacuum pump. The heating plate heats the medicine to the specified temperature in the circulating flow of the heating medium, and the water starts to evaporate and is gradually drawn away with the vacuum. This equipment is easy to control, can condense and recover the evaporated solvent, and the medicine is not easy to be contaminated during the drying process. It can be used for medicine drying, packaging material sterilization, and heat treatment.
Feature
- Microprocessor controller with LCD display, more accurate and reliable.
- Polished stainless steel chamber, durable and easy to clean.
- A tempered, bullet-proof double glass door ensures the safety of the operator and clear observation of the chamber.
- Door tightness can be adjusted, and silicon sealing. To keep vacuum states in the chamber can fill a working chamber with inert gas (inflation pressure ɗ 0.1 MPa).
- Storage, heating, testing, and drying can be performed in an environment without oxygen or in an inert atmosphere. It will not cause oxidation.
- Equipped with leakage protection.
- Vacuum degrees can be displayed and full-automatic controlled by a microcomputer for LC types.
Options
- Multi-segment programmable control
- Built-in printer
- RS485 interface
- Inert gas inlet valve
- Vacuum pump
Technical Specification
| Model | LVO-1B(6050) | LVO-0B(6020) | LVO-6090 | LVO-6210 |
| Image |  |
|
 |
|
| Power Supply | AC 220V, 50Hz | |||
| Volume(L) | 54L | 25L | 91L | 215L |
| Power Rating(kw) | 1.4kw | 0.5kw | 1.6kw | 2.2kw |
| Temperature Range(℃) | RT+5 ~250℃ | RT+5 ~200 | ||
| Temperature Fluctuation(℃) | ±1℃ | |||
| Display Resolution(℃) | 0.1℃ | |||
| Vacuum Pressure | <133 Pa | |||
| Chamber Size (W×D×H)cm | 42×35×37 | 30×30×28 | 45×45×45 | 56×60×64 |
| Exterior Size (W×D×H)cm | 71×59×53 | 58×57×45 | 61×66×145 | 72×82×175 |
| Package Size(W×D×H)cm | 82×70×69 | 70×64×60 | 78×76×163 | 89×92×193 |
| Net/Gross Weight(kg) | 75/106 | 35/50 | 90/145 | 145/195 |
| Model | LVO-1B(6050) | LVO-0B(6020) | LVO-6090 |
| Image | |
|
|
| Power Supply | AC 220V, 50Hz | ||
| Volume(L) | 50L | 91L | 215L |
| Power Rating（KW） | 1.4kw | 1.6kw | 2.2kw |
| Temperature Range（℃） | RT+10～250 | RT+10～200 | |
| Temperature Fluctuation | ±1℃ | ||
| Display Resolution | 0.1℃ | ||
| Vacuum Degree | <133 Pa | ||
| Chamber Size (W×D×H)cm | 42×35×37 | 45×45×45 | 56×60×64 |
| Exterior Size
(W×D×H)cm |
53×56×137 | 61×66×145 | 72×82×175 |
| Package Size (W×D×H)cm | 70×66×155 | 78×76×163 | 89×92×193 |
| Net/Gross（kg） | 75/106 | 90/145 | 145/195 |
